Spezifikation

Rahmen

"Genius Carbon / IMP Technology / HMF Main Frame#BB92 / Alloy SL 6011 swingarm#VLK Virtual 4 Link kinematic#27.5"" (2.6 & 2.8) and 29"" (2.4 & 2.6) tire compatible with Geo-BB adj.#SW dropouts for Boost 12x148mm#TBC Trunnion box construction"

Gabel

FOX 36 Float Performance Elite Air FIT4#3-Modes with low Speed adj. / Kabolt 15x110mm axle#44mm offset / tapered steerer / Reb. Adj. / Lockout#150mm travel

Dämpfer

FOX NUDE TR EVOL Trunnion#SCOTT custom w. travel / geo adj.#3 modes: Lockout-Traction Control-Descend#custom Ramp Adjust with linear and progressive settings#DPS / Reb. Adj.#Travel 150-100-Lockout / 185X55mm

Kurbel

Shimano XT FC-M8100-1 / Hollowtech 2#32T

Lenker

Syncros Hixon 1.5 / Alloy 7050D.B.#12mm rise / 9° / 780mm#Syncros Pro lock-on grips

Vorbau

"Syncros FL1.5 / Alloy 2014#integrated Spacer & Top Cap / 31.8mm / 6° / 1 1/8"""

Hebel

Shimano XT SL-M8100-IR / Rapidfire Plus#Ispec EV clamp

Bremsen

Shimano XT M8120 4 Piston Disc

Schaltwerk

Shimano XT RD-M8100 SGS#Shadow Plus / 12 Speed

Kette

Shimano SLX CN-M7100

Räder

Syncros Revelstoke 2.0 6 Bolt#F: 15x110mm, R: 12x148mm#30mm Tubeless ready rim 28H / Micro Spline#Syncros Axle w/Removable Lever with Tool

Kassette

Shimano XT CS-M8100-12 / 10-51 T

Reifen

"Maxxis Dissector / 2.6"" / 60TPI Foldable#Tubeless Ready / EXO 3C maxx Terra"

Sattelstütze

FOX Transfer Performance Elite Dropper Post#31.6mm / S size 125mm / M & L size 150mm / XL size 175mm

Sattel

Syncros Tofino 2.0 Regular#CRMO rails
